Applications

Features

Engine Fuel Pressure Measurement

Gauge, Absolute and Vacuum Pressure Measurement

Refrigeration and Air Compressor

Lifetime ˃100 M Cycles

Hydraulic Systems

Measuring Ranges from -1…. 250 Bar (Other ranges on request)

Water Pressure Measurement

Process Temperature from – 40 to + 125°C

Autoclaves & ETO Sterilizers

Wide Range of Pressure Ports and Electrical Connectors

Liquid & Gas Pressure Measurement

Housing and Diaphragm made of Premium Stainless Steel

Applications

Features

Automotive

Pressures from 0~1 up to 150 Bar (higher range on request)

Refrigeration & HVAC System

Accuracy up to 0.5% FS

Industrial Process Control

Excellent Corrosion resistance

Gas, Liquid Pressure Measurement

Small Profile, compact structure

Mechanical Engineering

Applications

Features

Hydraulics

Measuring diaphragm and pressure interface one-piece structure

Mechanical Engineering

Thread interface USES 7 degrees of taper sealing surface

Test Stand Design (Automotive Engineering)

Resistance to vibration, the instantaneous pressure impact resistance

Water Power Generating

Can measure pressure up to 600MPa

Applications

Features

Process Control System

Measuring ranges from 100mbar to 600bar

Steam and heat exchange

Absolute, gauge and sealed gauge

Hydraulic systems and valve

Accuracy: ±0.5% FSO, ±0.2% FSO (optional)

Machine building

Calibrated and temperature compensated

Pharmaceutical Industries

Stainless steel construction

Dairy Processing Industries

Wider operation temperature range

Paper & Pulp Industries

Variety of Pressure & Electrical connections

Output 4...20mA, 0...10V, 0...5V and ModBus RS485

Applications

Features

Process Control System

Measuring ranges from 100mbar to 250bar

Food & Beverages Industries

Absolute, gauge and sealed gauge

Pharmaceutical Industries

Accuracy: ±0.5% FSO, ±0.2% FSO (Optional)

Dairy Processing Industries

Calibrated and temperature compensated

Paper & Pulp Industries

Flush diaphragm construction

Petrochemical

Piezoresistive pressure sensor design

Sewage & Slurry Handling

Variety of Pressure & Electrical connections

Adhesives & Paint Industries

Output 4...20mA, 0...10V, 0...5V and ModBus RS485

Applications

Features

Control and process technology

Multi-functional display

Machine building and plant construction

Simple menu navigation

Pharmaceutical and hygienic industries

Conductive plastic case or stainless-steel case (optionally with electropolished surface)

Food industry

Large LC display

Chemical, petrochemical industry

Approvals for hazardous areas

Applications

Features

Equipment support

316L stainless steel diaphragm

Scientific experiment

Zero and full-scale span adjustable externally

Precision instrument

Short circuit protection and reverse polarity protection

Water supply and drainage

Power plant differential pressure

Excellent shock resistance, vibration resistance and electromagnetic compatibility resistance

Liquid level and Flow in process control

Applications

Features

Process control systems

Measuring ranges from 1.6bar to 250bar

Refrigeration and HVAC controls

Gauge type

Accuracy: ±0.5%FSO

Hydraulic systems and valve

Calibrated and temperature compensated

Mechanical and plant engineering

Ceramic pressure sensor design

Variety of Pressure & Electrical connections

Pumps and compressors

Output 4...20mA, 0...10V, 0.5...4.5V and others

Applications

Features

Process Control System

Measuring ranges from 100mbar to 600bar

Refrigeration and HVAC controls

Absolute, gauge and sealed gauge

Hydraulic systems and valve

Accuracy: ±0.5%FSO, ±0.2% FSO (optional)

Machine building

Calibrated and temperature compensated

Pumps and compressor

Stainless steel construction

Pharmaceutical Industries

Piezoresistive pressure sensor design

Dairy Processing Industries

Variety of Pressure & Electrical connections

Paper & Pulp Industries

Output 4...20mA, 0...10V, 0...5V and ModBus RS485

Applications

Features

Hydraulics

Measuring diaphragm and pressure interface one-piece structure

Mechanical Engineering

Thread interface USES 7 degrees of taper sealing surface

Test Stand Design (Automotive Engineering)

Resistance to vibration, the instantaneous pressure impact resistance

Water Power Generating

Can measure pressure up to 600MPa

Applications

Features

Process Control System

Measuring ranges from 100mbar to 250bar

Food & Beverages Industries

Absolute, gauge and sealed gauge

Pharmaceutical Industries

Accuracy: ±0.5% FSO, ±0.2% FSO (Optional)

Dairy Processing Industries

Calibrated and temperature compensated

Paper & Pulp Industries

Flush diaphragm construction

Petrochemical

Piezoresistive pressure sensor design

Sewage & Slurry Handling

Variety of Pressure & Electrical connections

Adhesives & Paint Industries

Output 4...20mA, 0...10V, 0...5V and ModBus RS485

Applications

Features

Process Control System

Measuring ranges from 100mbar to 250bar

Food & Beverages Industries

High Temperature application up to + 250°C

Pharmaceutical Industries

Absolute, gauge and sealed gauge

Dairy Processing Industries

Accuracy: ±0.5% FSO, ±0.2% FSO (Optional)

Paper & Pulp Industries

Calibrated and temperature compensated

Fuel Station

Flush diaphragm construction

Gas Dispenser

Piezoresistive pressure sensor design

Biological Industries

Variety of Pressure & Electrical connections

Pressure Instruments

Output 4...20mA, 0...10V, 0...5V and ModBus RS485

  Application

Liquid, Gas, Steam

Measuring range

0-100MPa

Output signal

4-20mA, 4-20mA+HART, customer

Reference accuracy

±0.1%

Stability

±0.2% URL/ years

Diaphragm

SS316L, Hastelloy C

Media temperature

-40-120℃

Protection class

 IP65

Process connection

M20 x 1.5(M), G1/2(M), G1/4 (M), 1/2NPT(M),14NPT(M) and Tri-clamp, Thread, Flange

Process Fluid

Liquid, gas

Measuring range

 0-100MPa

Working Temperature

 -25 to +95C

Current Output

4 – 20 mA   2 wires   Hart Protocol

Power Supply

24VDC

Process connections

Tri-clamp, Thread, Flange

Electrical Connections

1/2”NPT or M20 x 1.5

Enclosure

IP65

Intrinsically Safe

ia II C T6

Explosion proof

d II B T5

Diaphragm material

SS316L, Hastelloy C, Tantalum

Process Fluid

Liquid, Gas, or Steam flow as well as liquid Level, Density and Pressure

Measuring range

200Pa-10MPa

Working Temperature

-25 to +95C

Current Output

4 – 20 mA   2 wires   Hart Protocol

Power Supply

24VDC

Ambient Temperature

-25 to +120C

Process connections

1/4 – 18 NPT or 1/2 – 14 NPT

Electrical Connections

1/2”NPT or M20 x 1.5

Enclosure

IP 65

Intrinsically Safe

ia II C T6

Explosion proof

d II B T5

Diaphragm material

SS316L, Hastelloy C

Process Fluid

Liquid, gas, or steam flow as well as liquid level, density and pressure

Measuring range

200Pa-10MPa

Working Temperature

-25 to +95C

Current Output

4 – 20 mA   2 wires   Hart Protocol

Power Supply

24VDC

Ambient Temperature

-25 to +120C

Process connections

1/4 – 18 NPT or 1/2 – 14 NPT

Electrical Connections

1/2”NPT or M20 x 1.5

Enclosure

IP 65

Intrinsically Safe

ia II C T6

Explosion proof

d II B T5

Diaphragm material

SS316L, Hastelloy C
